Description

Power requirements: 208-230V, 16A, 50/60Hz, 1ph
Air supply requirements: 8-12 bar (115-175 psi)
Mount / demount tool: Hybrid leverless head
Clamping type: Center with Quick Clamp
Bead loosening type: Upper / lower roller
Match-mounting capable: Yes
Rim diameter range: 12-30 in. (305-762 mm)

Maximum…
Tire diameter 45 in. (1143 mm)
Wheel width 15 in. (381 mm)

Drive

7 / 17 rpm clockwise,
7 rpm counter-clockwise
Torque 880 Nm (650 ft-lbs.)

Dimensions
Height 2135 mm (84 in.)
Width 1425 mm (56 in.)
Depth With wheel lift: 1675 mm (66 in.)
Without wheel lift: 1400 mm (55 in.)
