Specifications
Display: 7? TFT IPS 1024?600 400CD
Graphics processor: Qualcomm Adreno 308 graphics processor (GPU) with 64-bit addressing
Sensor: Capacitive touch panel, USB/12C interface

Processor:
SC200R Series Snapdragon QCM2150 Quad-core
ARM Cortex-A53 64-bit CPU @ 1.3 Ghz
STM32F103 ? ARM Cortex M3 32-bit CPU
RAM: 2 GB LPDDR3
Hard drive: 16 GB eMMC
Operating system: Android 10.0
Audio peripherals: Devices 1 speaker CES-703116-28PM 8 Ohm 2 W
Wi-Fi: 802.11a/b/g/n, 150 Mbps, STA/AP/P2P 2402?2480 MHz 5 GHz
Bluetooth: 2.1 + EDR/3.0/4.1 LE/4.2 BLE 2400?2483.5 MHz
RF Power: 20 dBm
I/O Peripherals: USB 2.0 Devices x1
Main Battery: 3 V CR2032
Secondary Battery: NiMh 2.4 V ? 600 mAh
Liquid/Group: R1234yf / 1
Electronic Scale for Refrigerant (Accuracy) [g]: 10
Electronic Scale for Oil and UV Indicator (Resolution) [g]: ?
Pressure Sensor: Cl. 1.0
High Pressure Gauge [mm]: ? 80
Low Pressure Gauge [mm]: ? 80
Tank capacity [kg]: 10
Service pipe length [m]: 3
Filter unit: 1 combined filter + mechanical filter
Compressor (hermetic) [cm3]: 12
Vacuum pump: 100 l/min, two-stage, final pressure 0.05 mbar
Ambient temperature sensor (resolution) [?C]: 1
Refrigerant purity [kg]: 150 (SAE J2099)
Recovery efficiency:) 95 % (SAE J2788 / SAE J2843)
Maximum working pressure (PS) [bar]: 20
Safety device calibration [bar]: 20
Supply voltage [V]: 230
Frequency (Hz) : 50 (50/60)
Power [W]: 770
Operating Temperature (TS) [?C]: 5 40
Storage Temperature [?C]: ? 25 60
