Description

Functions

Air-conditioning pipeline cleaning
Clean the air-conditioning pipelines, remove sludge, powder and other impurities inside the pipelines, replace the refrigeration oil more thoroughly, improve compressor lubrication, and improve the refrigeration performance of the air-conditioning system. ?

Refrigerant recovery
The refrigerant in the automobile air conditioning system is purified and regenerated and then recycled into the working tank to meet the standards for reuse. ?

Vacuuming
Achieve vacuuming of air conditioning pipelines and equipment pipelines. ?

Refrigeration oil filling
Supports manual/automatic filling, and realizes intelligent and precise filling through the built-in electronic scale. ?

Refrigerant filling
Add refrigerant to the vehicle according to the set filling amount. ?

Automatic mode
According to the set parameters, automatically perform cleaning, recovery, vacuuming, filling of refrigeration oil, and lnject refrigerant and other operations. ?

Database
Equipped with automobile refrigerant model database, supports database calling, no manual setting is required. ?

Print
Supports printing of device execution results. ?

Parameters

Power supply: AC110V/AC220V 50Hz/60Hz
Recycling capacity: Gaseous state: 400g/min, Liquid state: 700g/min
Main engine power: 700W
Vacuum pump capacity: 2pa
Working temperature: 10~50?C
Tank: 12L
Electronic scale accuracy: ?10g
Filling rate: 800g/min
