Description

Maximum technological wheel diameter – 26 inches.
Chuck diameter – 320 mm.
Spindle speed – 50-2000 rpm.
Cutting speed – 0.1-1000 mm/min.
Spindle bore – 60 mm.
Spindle bore taper – MT6
Tool position – Manual 4-position tool stand
Tool stand section – 25×25 mm.
Spindle speed control – Automatic
Min. Motor adjustment unit – (Z) long 0.001 mm, (X) transverse 0.001 mm
Stand travel speed – (Z) long 8 m/min, (X) transverse 4 m/min.
Accuracy – 0.015 mm
Repeatability – 0.012 mm
Main motor power – 7.5 kW.
