Description

Features

? With a multifunctional color LCD panel and the most advanced DSP control technology. It features one button intelligent design to automatically store equipment information and to select the welding modes for various materials like steel, aluminium, stainless steel, copper and nickel. The user can store the welding parameters easily and safely.
? With a world famous brand of welding power supply, IGBT inverter pulsed technology and soft switching control technology. Unit has high protectiveness, extensive applicability and a world class welding performance.
? Designed with fender panel for gas cylinder to fix onto the machine.
? With two high quality welding guns with durable protective covers and specially designed gun holders
? IGBT inverter pulsed and soft switching control technology allows for energy efficient steady welding with fast arc ignition. Materials’ mechanical properties are maintained with less welding deformation and spatter. User can quickly and easily weld car bodies with various materials and achieve a perfect performance. There is also less post welding treatment work and less welding sparks are created.

Specification

Technical Data
Input Voltage: 230V or 400V
Rated Input Power: 10.5KVA
Rated Input Current: 15A
Min ~ Max Output Current: 35A/15.7V~320A/32V
Duty Cycle: 110A/100%~320A/65%
No-load Output Voltage: 60V
Efficiency: ?90%
Power Factor: ?0.95
Insulation Grade: F
Steel Wire Diameter: ?0.6-1.2mm
Alu Alloy Wire Diameter: ?0.8-1.2mm
Copper Alloy Wire Diameter: ?0.6-1.4mm
Wire Feeder: Four-roll Drive

Due to the continuous innovation and upgrade, our products’ features may be updated.
Please refer to actual products or contact us for more information.
