Description

Features
? Microprocessor control system optimizes the welding parameters. Due to the adoption of advanced digital control technology and user friendly design, all you have to do is to select the welding current corresponding to the workpiece thickness to achieve the best weld quality.
? Automatic mains voltage monitoring.
? Digital control system offers greater stability of the output power.
? The welding gun testing function to evaluate the usage status of the welder more comprehensively.
? Overheating protection.
? High precision time and power adjustment system.
? Designed to repair different kinds of car steels such as conventional steel, stainless steel, etc.
? Complete with triangle washers for dent pulling.
? Variety welding procedures are available such as shrinking, washer welding, dent pulling, spot welding, flattening, wavy wire welding, stud welding, OT washer welding, triangle washer welding etc.
? Digital display.
? Large pulling hammer and waveform wire welding.
? Stepless current regulation.

Specification

Input Voltage: AC 380V 50/60Hz
Input Power: 23KVA
Input Current: 58A
Max Welding Current: 5900A
Output Voltage: AC1-13V
One-side Welding Thickness: 0.8+1.2mm
Operation Way: Electronic timer continuously
Weld Time Range: 0-99s
Welding Current Regulation: Stepless

Due to the continuous innovation and upgrade, our products’ features may be updated.
Please refer to actual products or contact us for more information.

Accessories

F001 Pneumatic Vacuum Cupule: 1 set
F002 Pulling Hammer with Hook: 1 set
F003 Dent Pulling Spot Hammer: 1 set
F006 Wavy Wire: 15 pcs
F007 Carbon Rod: 5 pcs
F008 Spot Welding Electrode Tip: 1pc
F009 Carbon Rod Connector: 1pc
F010 Wavy Wire Electrode Tip: 1pc
F011 Washer Connector: 1pc
F014 Claw: 1pc
F015 Triangle Washer: 10 pcs
F016 Stud: 30 pcs
F017 ?12mm Washer: 15 pcs
F017 ?10mm Washer: 15 pcs
F030 OT Washer: 20 pcs
F034 Stud Connector: 1 pc
