Description

Features
? Microprocessor control system optimizes the welding parameters. Due to the adoption of advanced digital control technology and user friendly design, all you have to do is select the welding current corresponding to the workpiece thickness to achieve the best weld quality.
? Reliable transformer with HUA curved silicon steel sheet, 100% copper windings (optional).
? With DELIXI, OMRON and PANASONIC high quality relay.
? High precision power control system.
? The whole spot gun body is cast in polyamide.
? Sliding type pulling hammer.
? Complete with crossbar lifter to accommodate any repair task for the whole aluminium car body.
? Suitable for dent pulling of aluminium and different kinds of car steels.
? High welding strength without damage to the metallic coatings and paint surfaces on the back.
? Digital display, simple to operate and easy to use.
? Spottable stud bolt diameter 4mm-8mm.
? Additional aluminium MIG welder is available as an option.

Specification

Technical Data
Input voltage: AC220V 50/60Hz 1ph
Rated power: 2.0KVA
Fuse: 4-10A
Insulation grade: H
No-load voltage: 60-240V
Spottable stud diameter: ?4-?10mm
Duty cycle: 80%

Due to the continuous innovation and upgrade, our products’ features may be updated.
Please refer to actual products or contact us for more information.

Dent Repair Glue Pulling Kit

This method can quickly repair minor collisions to the car body. After confirming the elastic deformation of the car body, safely and quickly repair it without damaging the paint surface or disassembling any components.
