Description

Features
? With an advanced integrated circuit, functional modules and the new technology of high-performance switching for convenient adjustments, this unit is easy to learn how to use.
? Independent development of mature technology, high reliability, easy operation and high efficiency.
? The microprocessor control system optimizes the welding parameters. Using advanced digital control technology and user friendly design, all you have to do is select the welding current to achieve the best welding results.
? Voltage auto detect function.
? Multi-bridge rectifier.
? Complete with a VPOWER wire feeder.
? Practical, reliable and advanced technology.
? With HUA curved silicon steel sheet and energy efficient main transformer.
? With DELIXI, OMRON and Panasonic high quality relays.
? Taiwan TIANWEI switch.
? Switch with gun testing function.
? With the world famous EMIR brand welding gun.
? Complete with tool box and anti-blocking agent.

Technical Data

Input Voltage: AC380V 50/60Hz
RMS Input Current: 16.8KVA
MAX Input Current: 12.5A
Min~Max Current/Voltage: 35A/17V~250A/26.5V
Duty Cycle: 35%
No-load Voltage: 20-37V
Insulation Grade: F
Welding Wire: ?0.8-1.0mm
Welding Torch Cable: L: 3M ?0.8-1.0mm
Regulation: 6 or 10
