Description

Size:
Outside Size: 7000*4000*3300 mm(L*W*H)
Inside Size: 6900*3900*2600 mm(L*W*H)
Front Door: 3000*2700mm(W*H)
Side Door: 700*2000mm(W*H)

Wall Panel:
Walls: EPS colorful steel skin panel
Wall Thickness: 50 mm thick
Material: Tongue & Groove style, anti-flame and heat insulation.

Basement floor:
Galvanized steel sheet and square steel pipe assembling, 2 rows of grid plates made by felt bar and round steel. 3 rows of diamond plates.

Intake and Exhaust system:
Two sets of 3kw fans for intaking air, air capacity 20000m3/h
One set of 4kw fan for exhausting air, air capacity 12500m3/h

Urification syste:
Pre-filter, filtering rate > 83%
m600G high efficiency ceiling filter, filtering rate > 97%
floor filter(fiberglass filter), filtering rate > 70%

Heating System1: Italy Riello FS20 Gas Burner, 200000Kcal/h.
Stainless Steel Heat exchanger, argon arc welding.
Auto- damper for changing spraying and baking.

HeatingSystem2: Infrared heating system, 3-tubes/unit, totally 8 heating units, 24kw
