Description

Description
Semi-automatic swing arm tire changer machine for wheels with a rim from 14? to 26? (max. tire diameter 1143 mm./45?, max. tire width 406mm./16?). Suggested for low-mid volume shops, garages and repair shops.

EX-1291IT tire changer machine represents the PULI entry-level solution, suggested for low-mid volume shops, garages and repair shops. Simplicity is the strong point of this model, which combines solid and reliable design, PULI experience and a classic well-known operating mode.

Features:

1. Pneumatic locking device between the vertical arm and 098 help arm, patent unique function make the locking operation extremely easy
2. Semi-automatic swing arm
3. The round column is used as the air tank
4. Clamping jaws are totally one-step die casting
5. Quick air booster, esp. suitable for low profile tyres
6. Max working clamping 26?
7. RIM CLAMPING METHOD:26? large turntable and high power motor, which increase working strength
009 MULTI-FUNCTION LEFT HELP ARM
* 360? rotary tyre pressing help am, combined tyre pressing head has functions of lifting
tyre, pressing tyre, and central positioning.
* Central positioning function which can make wheel and turntable homocentric
* Function of lifting tire makes it easy to raise the low profile tires
INTERNATIONAL PATENT RIGHT 098 HELP ARM:
SIMPLE, RELIABLE AND STABLE
* Nylon pressing roller helps to build a little space 2-3mm between the rim and the bird
head, to avoid metal bird head-scratching the rim.
* Easy to operate, one man can dismantle big tire easily, such as tire for BMW 7serles

Additional information
External clamping
12~23″

Internal clamping
14~26″

Max.Wheel diameter
?1143mm (45″)

Max.Wheel width
?406mm (16″)

Working Pressure
8-10bar (116-145 psi)

Opitonal Power supply
110 V (1 ph)/ 220 V (1 ph/3 ph)/ 380 V (3 ph)

Optional Mottor power
0.55/0.75/1.1 kw

Noise Level
<75 dB Dimension(main body) 900*1130*950mm (3.0*3.7*3.1ft) N/G weight(main body) 244/272 kg (538/600 lbs)
